SN-RF1E Heat Sealer
Standards
QB/T 2358,ASTM F 2029,YBB 00122003
Application Fields
Packaging | Food | Pharmaceuticals | New Materials | Chemical Industry | Printing
Intended Use
Suitable for heat sealing tests of various film materials, including plastic films, plastic composite films, paper-plastic composite films, co-extruded films, aluminized films, aluminum foil, and aluminum foil composite films.
Operating Principle
Utilizes the heat-pressure sealing method. The specimen is placed between the upper and lower heat-sealing jaws, and sealing is completed under preset temperature, pressure, and time conditions.
Product Features
- Dual temperature, dual control, and dual display. Features an external three-axis cylinder for smoother downward pressure; all core components are imported.
- Digital P.I.D. temperature control technology not only reaches the set temperature rapidly but also effectively eliminates temperature fluctuations.
- A wide range of temperature, pressure, and time controls can satisfy various experimental conditions of users.
- Offers both manual and foot-switch start modes, along with anti-scald safety designs to ensure user convenience and safety.
Technical Parameters
|
Item |
Parameter |
|
Heat Sealing Temp |
Ambient +5 ~ 300°C |
|
Temp. Accuracy |
±0.1℃ |
|
Sealing Time |
0.01s~99.99h |
|
Sealing Pressure |
0~8kg(0~0.8Mpa) |
|
Sealing Area |
300 * 5mm or 300 * 10mm Smooth (Lower jaw with silicone pad) |
|
Heating Form |
Dual Heating |
|
Dimensions |
600mm*400mm*550mm |
|
Power Supply |
AC 220V/50Hz |
Equipment Configuration
Standard Configuration
Mainframe, Foot Switch, Power Cable
User-provided Items
Compressed Air
